V-SOL V3600D8 8 Port 10G EPON OLT

Brand: VSOL

Title: V-SOL V3600D8 8 Port 10G EPON OLT

Model: V3600D8

Code: 2110929601

Category: Networking / ISP / OLT

Product Type: OLT

Price: 84000

Warranty: 1

Availability: Available/In Stock

Description:

V-SOL V3600D8 8 Port 10G EPON OLT

Technical Specifications:

Model: V3600D8

Form Factor: 1U 19-Inch Standard Rackmount Box
EPON Ports: 8 × EPON Ports (SFP Slots)
Uplink Interfaces: * 4 × RJ45 Gigabit Ethernet (GE) Ports
4 × SFP (1GE) / SFP+ (10GE) Slots
Max Splitting Ratio: 1:64 (Up to 512 ONUs/ONTs per OLT)
EPON Port Speed: Symmetrical 1.25 Gbps (Upstream & Downstream)
Optical Parameters: Wavelength: TX 1490nm, RX 1310nm | Connector Type: SC/PC or SC/UPC | Fiber Type: 9/125µm SMF (Single Mode Fiber)
Supported PON Modules: EPON PX20, PX20+, PX20++, PX20+++ Enhanced Modules
Transmission Distance: Up to 20 KM
Switching Performance: Backplane Bandwidth: 128 Gbps | Port Forwarding Rate: 95.232 Mpps
Layer 2 Features: 16K MAC Address table, 4096 VLANs, Port VLAN, QinQ, LACP (Static/Dynamic), IGMP Snooping (v1/v2/v3)
Layer 3 Features: Static Routing, Dynamic Routing (RIP v1/v2, OSPFv2), ARP Proxy, DHCP Server/Relay/Snooping
Security & Access Control: Access Control List (ACL), Broadcast/Storm Control, Port Isolation, IP Source Guard, RADIUS & TACACS+
Management Ports: 1 × 10/100BASE-T out-band port, 1 × CONSOLE port, 1 × Type-C USB (for console), 1 × USB 2.0
Management Modes: EMS, WEB, SNMP, Telnet, CLI, SSH v2
Power Configuration: * Dual Power Slot (Supports 1*AC, 2*AC, 2*DC, or 1*AC + 1*DC Hot-swap)
AC Range: 100~240V, 50/60Hz | DC Range: -36V~-75V

Physical Specs: Dimensions: 442mm × 200mm × 43.6mm | Power Consumption: ≤ 45W

Key Features:

High-Density 1U Pizza-Box Design:
The V-SOL V3600D8 is designed in a highly compact, 1U standard rackmount form factor. This low-profile "pizza-box" design makes it exceptionally easy to deploy in limited room spaces, small cabinets, basements, or shared racks with wireless base stations across Bangladesh.

Scalable 8-Port EPON Fiber Distribution:
Featuring 8 independent EPON ports, this OLT supports a splitting ratio of up to 1:64 per port. This enables local internet service providers to connect up to 512 subscriber ONUs/ONTs from a single 1U device, significantly optimizing fiber resources and minimizing initial infrastructure costs.

Future-Proof 10G Uplink Capabilities:
Say goodbye to network congestion. The V3600D8 boasts a flexible uplink combination featuring 4 Gigabit RJ45 copper ports and 4 SFP/SFP+ slots that support blazing-fast 10G uplinks. Combined with a robust 128 Gbps backplane bandwidth, it ensures fluid data delivery for high-bandwidth areas.

Advanced Layer 3 Routing (OSPF & RIP):
Engineered for advanced network architectures, this EPON OLT brings Layer 3 routing directly to your distribution layer. It natively supports static routing along with dynamic routing protocols (RIP v1/v2 and OSPF v2), allowing ISPs to manage traffic distribution, IP subnets, and data filtering with enterprise-grade efficiency.

Carrier-Grade Redundancy & Link Protection:
Ensure uninterrupted internet services for your clients. The V3600D8 offers comprehensive link and uplink redundancy protection through LACP, STP, RSTP, and MSTP protocols. It also includes advanced specialized designs for system breakdown prevention, making troubleshooting quick and painless.

Modular Dual Power Supply Redundancy:
To battle frequent load-shedding and power instability in regional areas of Bangladesh, the V3600D8 features dual hot-swappable power slots. ISPs can customize their setups with Dual AC, Dual DC, or hybrid AC+DC configurations to guarantee that the central fiber node stays powered 24/7.

Streamlined Remote Management via EMS:
Take full control of your broadband infrastructure effortlessly. The device fully supports automated ONT discovery, link detection, and remote firmware upgrades. Network operators can manage everything using a standard WEB browser interface, CLI, Telnet, SNMP, or V-SOL’s dedicated EMS platform.

The V-SOL V3600D8 is a professional, high-performance 8-Port Layer 3 EPON OLT tailored to drive affordable, stable, and high-speed broadband deployments throughout Bangladesh. Specially engineered for regional Internet Service
Providers (ISPs), local cable operators (MSOs), and corporate network grids, this versatile 1U rackmount OLT empowers network owners to scale their Fiber-to-the-Home (FTTH) and Fiber-to-the-Building (FTTB) footprints seamlessly.

Driven by an efficient switching architecture with a 128 Gbps backplane, the V3600D8 utilizes 8 dedicated EPON slots to seamlessly serve up to 512 end-user ONUs across transmission distances of up to 20 KM. What sets this
model apart in its class is the inclusion of integrated Layer 3 dynamic routing capabilities (RIP/OSPF) alongside dual 10G SFP+ uplink ports, ensuring your network is ready to handle high-definition IPTV streaming, corporate lease lines,
and competitive online gaming demands without breaking a sweat. Completed with modular, hot-swappable dual power supply options (AC/DC) to safeguard against unexpected power fluctuations, the VSOL V3600D8 represents the ultimate
future-proof investment for Bangladeshi ISPs seeking enterprise network resilience and elite uptime at a highly competitive price point.

Buy VSOL V3600D8 8 Port 10G EPON OLT in Bangladesh at the best price. This high-performance carrier-grade OLT supports 8× 10G EPON ports with up to 1:256 split ratio, 880Gbps switching capacity, and multiple uplink options including
10GE, 25GE, and 100GE. Ideal for ISP, FTTH, and FTTx networks, it ensures stable, scalable, and high-speed fiber broadband solutions for large user deployments in Bangladesh.
