V-SOL V1600G1-B 8-Port GPON OLT
Model: V1600G1-B
Brand: VSOL
Code: 2110929630
V-SOL V1600G1-B 8-Port GPON OLT
Technical Specifications:
Model: V1600G1-B
Chassis Type: 1U 19-inch Standard Rackmount Case
GPON Interface: 8 × GPON Ports (SFP Slots)
Uplink Interface: 8 × Ports (4 × 10/100/1000 Mbps RJ45 Ethernet Ports + 4 × 1GE/10GE SFP+ Slots)
Split Ratio: 1:128 Max Split Ratio per GPON port
Maximum Capacity: Supports up to 1024 ONUs/ONTs simultaneously
Backplane Bandwidth: High-capacity switching fabric for non-blocking wire-speed forwarding
VLAN Support: 802.1Q, 802.1p, QinQ (VLAN Stacking), VLAN Translation
LED Status Indicators: Power, SYS, PON, Link/Act for Uplink Ports
Power Supply: Dual Redundant Power Supplies (AC: 90~264V / DC: -36~-72V)
Physical Specs: Heavy-duty Metal Body | Weight: ~4.5 kg | Dimensions: 442 × 320 × 44 mm
Warranty: 1-Year Official Manufacturer Warranty
Key Features & Benefits:
High-Density GPON Access: Equipped with 8 GPON ports supporting a 1:128 split ratio, allowing ISPs to connect up to 1024 downstream ONT/ONU devices from a single 1U unit.
10G Ultra-Fast Uplink: Features 4× 10G SFP+ uplink ports alongside 4× Gigabit RJ45 ports, ensuring massive backhaul bandwidth and zero network bottlenecks.
Carrier-Grade Redundant Power: Designed with dual hot-swappable power supplies (AC+DC options available) to guarantee 24/7 uninterrupted network uptime and high reliability.
Layer 2/3 Switching Features: Fully supports advanced Layer 2/3 protocols, including QinQ, VLAN translation, IGMP Snooping/Proxy for IPTV, QoS bandwidth control, and static routing.
Robust Security & Firewall: Packed with Access Control Lists (ACL), storm control, MAC/IP/Port binding, and anti-DDoS protection to safeguard the core ISP network from malicious attacks.
Comprehensive Remote Management: Supports flexible management options including CLI (Telnet/SSH), Web-based GUI, SNMP, and EMS management software for easy mass configuration and monitoring.
Standard 1U Rackmount Design: Compact, space-saving 19-inch form factor fits easily into standard server racks, optimizing space in data centers or local POP points.
Product Overview:
The V-SOL V1600G1B is a high-performance, carrier-grade 8-Port GPON OLT designed specifically for small-to-medium FTTx (Fiber to the Home/Building) network deployments across Bangladesh. Packing massive capacity into a compact 1U rackmount chassis,
this OLT is powered by enterprise-grade switching architecture, allowing local Internet Service Providers (ISPs) to deliver ultra-fast, stable internet, IPTV, and VoIP services to up to 1,024 subscribers simultaneously.
Equipped with 4 built-in 10G SFP+ uplink slots, the V1600G1B ensures lightning-fast data throughput straight to your core network without any bottlenecks. Its dual redundant power supply system guarantees maximum network uptime,
making it an exceptionally reliable, cost-effective, and scalable solution for growing ISPs, corporate buildings, and smart community networks.
V-SOL V1600G1-B 8 Port GPON OLT in Bangladesh offers high-performance FTTH fiber network solution with 8 GPON ports, 10G uplink, L3 routing support, and 1:128 splitting ratio. Ideal for ISP and telecom operators, this 1U rack-mountable OLT ensures stable, scalable, and cost-effective broadband deployment across Bangladesh.
V-SOL V1600G1-B 8-Port GPON OLT
The V-SOL V1600G1-B 8-Port GPON OLT is designed for Internet Service Providers (ISPs) deploying FTTH and FTTB fiber-optic networks. It features 8 GPON ports, 4 Gigabit Ethernet RJ45 ports, and 4 SFP/SFP+ uplink slots for connecting access networks to the core network. With support for a maximum 1:128 splitting ratio per GPON port and up to 1,024 ONUs/ONTs, it provides a scalable solution for expanding broadband infrastructure.
Key Features
- 8 GPON Ports: Supports high-density fiber access for FTTH and FTTB deployments.
- 10G Uplink Support: Includes 4 × Gigabit Ethernet RJ45 ports and 4 × 1GE/10GE SFP+ slots.
- Scalable Subscriber Capacity: Supports up to 1,024 ONUs/ONTs according to the supplied specifications.
- Flexible Split Ratio: Supports up to 1:128 splitting per GPON port, subject to optical budget and network design.
- VLAN Management: Supports 802.1Q, 802.1p, QinQ, and VLAN translation.
- Network Management: Supports Web management, CLI, SNMP, and EMS.
- Redundant Power Options: Supports AC and DC power configurations with dual power supplies.
- Space-Saving Design: 1U chassis fits standard 19-inch equipment racks.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | V-SOL |
| Model | V1600G1-B |
| Product Code | 2110929630 |
| Product Type | GPON OLT |
| GPON Interfaces | 8 × GPON SFP slots |
| Uplink Interfaces | 4 × GE RJ45 + 4 × 1GE/10GE SFP+ slots |
| Maximum Splitting Ratio | 1:128 per GPON port |
| Maximum ONU/ONT Capacity | Up to 1,024 |
| VLAN Features | 802.1Q, 802.1p, QinQ, VLAN translation |
| Management | Web GUI, CLI, SNMP, EMS |
| Power Supply | AC 90–264V / DC −36V to −72V |
| Chassis | 1U, 19-inch rackmount |
| Dimensions | 442 × 320 × 44 mm |
| Weight | Approximately 4.5 kg |
| Price | ৳123,000 |
| Warranty | 1 year |
| Availability | In Stock |
Why Choose the V-SOL V1600G1-B?
The V-SOL V1600G1-B combines 8 GPON ports, flexible uplink connectivity, VLAN management, and a compact rackmount design. It is suitable for ISPs and network operators planning to expand FTTH/FTTB broadband services.
Frequently Asked Questions
1. How many GPON ports does the V-SOL V1600G1-B have?
It has 8 GPON ports.
2. Does this OLT support 10G uplinks?
Yes. It has four SFP+ uplink slots specified for 1GE/10GE connectivity. Compatible modules are required.
3. What is its maximum splitting ratio?
The specified maximum is 1:128 per GPON port. The practical ratio depends on the optical budget and network configuration.
4. How many ONUs/ONTs can it support?
The supplied specifications state a maximum of 1,024 ONUs/ONTs.
