V-SOL V1600GS 1-Port GPON OLT with 10GE Uplink
Model: V1600GS
Brand: VSOL
Code: 2110929628
V-SOL V1600GS 1-Port GPON OLT with 10GE Uplink
Technical Specifications:
Model: V1600GS
Chassis / Design: 1U Box-Type / Mini Metal Shell (Rack Mountable)
PON Interface: 1 × GPON Port (ITU-T G.984.x standard)
Uplink Interface: 3 Ports (2 × 10/100/1000Mbps RJ45 Ethernet Ports + 1 × 10GE SFP+ / GE SFP Slot)
PON Speed: Downstream: 2.488 Gbps | Upstream: 1.244 Gbps
Max Splitting Ratio: 1:128 (Supports up to 128 ONUs/ONTs)
Transmission Distance: Up to 20 KM
Wavelength: TX 1490nm, RX 1310nm
Layer 2 Features: 1K MAC address, 4096 VLANs, Port Isolation, Storm Control, QinQ, 802.1D & 802.1W
Layer 3 & Advanced Features: Static Routing, DHCP Server/Relay/Snooping, NAT, DMZ, ACL, IPv6 Support
Multicast: IGMP Snooping (v1/v2/v3), 256 IP Multicast Groups
Management Port: 1 × Console Port (or Type-C USB-COM)
Management Mode: WEB GUI, CLI, Telnet, SNMP
Physical Specs: Net Weight: ~1.07 kg | Dimensions: 224 × 199 × 43.6 mm
Surge Protection: 4KV Power Supply Protection | 1KV Device Interface Protection
Warranty: 1-Year Official Manufacturer Warranty (or as applicable)
Key Features & Benefits:
High-Density Single PON Efficiency: Equipped with 1× GPON port supporting up to a 1:128 splitting ratio, allowing ISPs to connect up to 128 end-users or ONTs from a single compact unit.
10GE Ultra-Fast Uplink: Features a 10G SFP+ uplink slot alongside dual Gigabit RJ45 ports, eliminating bandwidth bottlenecks and ensuring smooth traffic aggregation to the core network.
Long-Distance Coverage: Delivers stable, high-speed fiber connectivity with a transmission range of up to 20 KM, making it ideal for both urban and rural deployment layouts.
Carrier-Grade Layer 2/3 Networking: Supports advanced routing and switching features, including static routing, dynamic ARP, DHCP Option82, NAT, QoS, and 4096 VLAN configurations for enterprise-grade security and isolation.
IPTV & Triple-Play Ready: Integrated with IGMP Snooping and Multicast capabilities to ensure lag-free, seamless streaming for IPTV, VoIP, and broadband services.
Comprehensive IPv6 Dual-Stack: Fully future-proofed with native IPv6 routing, SLAAC, MLD snooping, and specialized IPv6 ACL security rules.
Robust Enterprise Security: Built-in firewalls, Access Control Lists (ACLs) based on MAC/IP/Port, broadcasting storm resistance, and port isolation shield the network from malicious attacks.
Flexible Management & Monitoring: Network administrators can effortlessly configure, monitor, and upgrade connected ONTs remotely using user-friendly Web UI, CLI, Telnet, or SNMP.
Industrial-Grade Durability: Encased in a mini metal shell with 4KV power surge lightning protection, ensuring stable operation even under fluctuating power conditions.
Product Description:
The V-SOL V1600GS is a high-performance, ultra-compact, and budget-friendly 1-Port GPON OLT designed specifically for small to medium-sized Internet Service Providers (ISPs), SOHO environments, and localized FTTH (Fiber to the Home) deployments across Bangladesh.
Housed in a space-saving 1U mini metal chassis, this single-PON OLT is the perfect alternative to bulkier, high-cost headend equipment, offering an entry-level core solution without sacrificing premium features.
Despite its mini footprint, the V1600GS packs a powerful punch with a massive 1:128 optical splitting ratio and a 20KM transmission range, enabling local network operators to serve up to 128 clients from a single fiber strand.
To ensure zero network congestion, it is strategically engineered with a 10GE SFP+ uplink port alongside two Gigabit Ethernet RJ45 ports for high-capacity backhaul aggregation.
Management is incredibly seamless, allowing system admins to handle ONT auto-discovery, link detection, and remote software upgrades via a simple Web GUI, CLI, or SNMP. Whether you are expanding internet coverage in residential areas, student hostels,
commercial buildings, or remote corporate parks, the VSOL V1600GS stands out as an exceptionally reliable, high-value, and cost-effective solution for building a modern broadband infrastructure.
Brand: OLT / VSOL
Title: V-SOL V1600GS 1-Port GPON OLT with 10GE Uplink
Model: V1600GS
Code: 2110929628
Category: Networking / ISP / OLT
Product Type: OLT
Price: 31500
Warranty: 1
Availability: Available/In Stock
Description:
V-SOL V1600GS 1-Port GPON OLT with 10GE Uplink
Technical Specifications:
Model: V1600GS
Chassis / Design: 1U Box-Type / Mini Metal Shell (Rack Mountable)
PON Interface: 1 × GPON Port (ITU-T G.984.x standard)
Uplink Interface: 3 Ports (2 × 10/100/1000Mbps RJ45 Ethernet Ports + 1 × 10GE SFP+ / GE SFP Slot)
PON Speed: Downstream: 2.488 Gbps | Upstream: 1.244 Gbps
Max Splitting Ratio: 1:128 (Supports up to 128 ONUs/ONTs)
Transmission Distance: Up to 20 KM
Wavelength: TX 1490nm, RX 1310nm
Layer 2 Features: 1K MAC address, 4096 VLANs, Port Isolation, Storm Control, QinQ, 802.1D & 802.1W
Layer 3 & Advanced Features: Static Routing, DHCP Server/Relay/Snooping, NAT, DMZ, ACL, IPv6 Support
Multicast: IGMP Snooping (v1/v2/v3), 256 IP Multicast Groups
Management Port: 1 × Console Port (or Type-C USB-COM)
Management Mode: WEB GUI, CLI, Telnet, SNMP
Physical Specs: Net Weight: ~1.07 kg | Dimensions: 224 × 199 × 43.6 mm
Surge Protection: 4KV Power Supply Protection | 1KV Device Interface Protection
Warranty: 1-Year Official Manufacturer Warranty (or as applicable)
Key Features & Benefits:
High-Density Single PON Efficiency: Equipped with 1× GPON port supporting up to a 1:128 splitting ratio, allowing ISPs to connect up to 128 end-users or ONTs from a single compact unit.
10GE Ultra-Fast Uplink: Features a 10G SFP+ uplink slot alongside dual Gigabit RJ45 ports, eliminating bandwidth bottlenecks and ensuring smooth traffic aggregation to the core network.
Long-Distance Coverage: Delivers stable, high-speed fiber connectivity with a transmission range of up to 20 KM, making it ideal for both urban and rural deployment layouts.
Carrier-Grade Layer 2/3 Networking: Supports advanced routing and switching features, including static routing, dynamic ARP, DHCP Option82, NAT, QoS, and 4096 VLAN configurations for enterprise-grade security and isolation.
IPTV & Triple-Play Ready: Integrated with IGMP Snooping and Multicast capabilities to ensure lag-free, seamless streaming for IPTV, VoIP, and broadband services.
Comprehensive IPv6 Dual-Stack: Fully future-proofed with native IPv6 routing, SLAAC, MLD snooping, and specialized IPv6 ACL security rules.
Robust Enterprise Security: Built-in firewalls, Access Control Lists (ACLs) based on MAC/IP/Port, broadcasting storm resistance, and port isolation shield the network from malicious attacks.
Flexible Management & Monitoring: Network administrators can effortlessly configure, monitor, and upgrade connected ONTs remotely using user-friendly Web UI, CLI, Telnet, or SNMP.
Industrial-Grade Durability: Encased in a mini metal shell with 4KV power surge lightning protection, ensuring stable operation even under fluctuating power conditions.
Product Description:
The V-SOL V1600GS is a high-performance, ultra-compact, and budget-friendly 1-Port GPON OLT designed specifically for small to medium-sized Internet Service Providers (ISPs), SOHO environments, and localized FTTH (Fiber to the Home) deployments across Bangladesh.
Housed in a space-saving 1U mini metal chassis, this single-PON OLT is the perfect alternative to bulkier, high-cost headend equipment, offering an entry-level core solution without sacrificing premium features.
Despite its mini footprint, the V1600GS packs a powerful punch with a massive 1:128 optical splitting ratio and a 20KM transmission range, enabling local network operators to serve up to 128 clients from a single fiber strand.
To ensure zero network congestion, it is strategically engineered with a 10GE SFP+ uplink port alongside two Gigabit Ethernet RJ45 ports for high-capacity backhaul aggregation.
Management is incredibly seamless, allowing system admins to handle ONT auto-discovery, link detection, and remote software upgrades via a simple Web GUI, CLI, or SNMP. Whether you are expanding internet coverage in residential areas, student hostels,
commercial buildings, or remote corporate parks, the VSOL V1600GS stands out as an exceptionally reliable, high-value, and cost-effective solution for building a modern broadband infrastructure.
