V-SOL V2808-8GL-PSE XPON 8-Port Gigabit PoE+ MDU ONU

Brand: ONU / VSOL

Title: V-SOL V2808-8GL-PSE XPON 8-Port Gigabit PoE+ MDU ONU

Model: V2808-8GL-PSE

Code: 2110930420

Category: Networking / ISP / ONU

Product Type: ONU

Price: 9000

Warranty: 1

Availability: Available/In Stock

Description:

V-SOL V2808-8GL-PSE XPON 8-Port Gigabit PoE+ MDU ONU

Technical Specifications:

Model: V2808-8GL-PSE

Device Type: MDU (Multi-Dwelling Unit) ONU / PoE Switch
PON Interface: 1 × XPON Port (GPON/EPON Auto Adaptive) | SC/UPC Connector
Optical Specs: TX Wavelength: 1310nm, RX Wavelength: 1490nm | Sensitivity: -27 dBm | Distance: Up to 20KM
LAN Interface: 8 × 10/100/1000 Mbps Gigabit Ethernet Ports
PoE Support: IEEE 802.3af/at PoE+ on all 8 Gigabit LAN ports
Power Output/Budget: Max Total Power Budget up to 130W (with PoE supply)
VLAN Support: 802.1Q VLAN, Voice VLAN, QoS, and Fine-grained Business Control

Physical Specs: Premium Metallic/Durable Body | Weight: ~0.615kg | Dim: 205 × 125 × 28 mm

Operating Power: DC 54V/2.4A External Power Adapter

Warranty: 1-Year Official Manufacturer Warranty

Key Features:

2-in-1 Combo Device: Functions as both a high-capacity XPON ONU and an 8-Port Gigabit PoE Switch, eliminating the need for separate devices.

XPON Dual Mode (GPON/EPON): Automatically detects and adapts to both GPON (ITU-T G.984) and EPON (IEEE 802.3ah) OLT network architectures.

Full Gigabit PoE+ Ports: Features 8× 10/100/1000 Mbps auto-adaptive RJ45 ports that can directly power up PoE-supported IP cameras, Wi-Fi Access Points, and VoIP phones.

High PoE Power Budget: Supports up to 130W total power supply, enabling stable data transmission and concurrent power delivery to multiple heavy-duty network devices.

MDU Architecture for Operators: Specially engineered for Multi-Dwelling Units (MDUs), corporate offices, building automation, and multi-tenant broadband distribution.

Carrier-Grade Remote Management: Comprehensive remote management capabilities via TR-069, OMCI, OAM, and Web UI for easy updates, monitoring, and configurations.

Advanced Security & Control: Offers robust firewall protections, MAC/IP filtering, fine-grained access controls, and anti-looping features to maintain network integrity.

Industrial-Grade Reliability: Built to operate smoothly in temperatures ranging from -10°C to +55°C, ensuring continuous performance under various environmental conditions.

Product Overview:

The V-SOL V2808-8GL-PSE is an enterprise-grade, highly efficient XPON MDU (Multi-Dwelling Unit) ONU designed specifically for network operators, FTTX deployments, and complex surveillance networks across Bangladesh. Powered by VSOL's mature optical technology,
this dual-mode device automatically adapts to both GPON and EPON infrastructure, making network expansion hassle-free for local Internet Service Providers (ISPs) and system integrators.

Equipped with 8 Full Gigabit Ethernet ports featuring advanced IEEE 802.3af/at PoE+ support, the V2808-8GL-PSE acts as a bridge between high-speed fiber optics and multi-device networks. It can single-handedly power up and connect up to 8 IP Security
Cameras or wireless Access Points without requiring extra power sockets or separate PoE injectors. Housed in a durable, compact chassis, it is the ultimate all-in-one solution for corporate offices, apartment buildings, internet hot-spots, and large-scale
CCTV security monitoring setups.
