V-SOL V2802PH Wall Mount XPON ONU (1GE + 2.5GE Ports)
Model: V2802PH
Brand: VSOL
Code: 2110930421
V-SOL V2802PH Wall Mount XPON ONU (1GE + 2.5GE Ports)
Technical Specifications:
Model: V2802PH
Form Factor: 86-Type Wall Panel Mount Design
Chipset: High-performance Realtek XPON Chipset
PON Interface: 1 × XPON Port (GPON Class B+ / EPON PX20+ Auto Adaptive)
LAN Interfaces: * 1 × 10/100/1000 Mbps Gigabit Ethernet (1GE) Port
1 × 10/100/1000/2500 Mbps Multi-Gigabit Ethernet (2.5GE) Port
Optical Parameters: TX Wavelength: 1310nm, RX Wavelength: 1490nm | TX Optical Power: 0~+4dBm | RX Sensitivity: -27dBm
Transmission Distance: Up to 20 KM
Optical Safety / Overload Protection: -3dBm (EPON) | -8dBm (GPON)
VLAN Support: VLAN Tag Mode, Transparent Mode, Trunk Mode (Max 8 VLANs), 1:1 Translation Mode, Auto VLAN Detection
LED Status Indicators: PWR, PON, LOS, WAN, LAN1 (1GE), LAN2 (2.5GE)
Physical Specs: Net Weight: 160g | Dimensions: 86 × 86 × 33.3 mm (Fits standard 86-type electrical boxes)
Warranty: 1-Year Official Manufacturer Warranty
Key Features:
86-Type Flush Wall Mount Design: Specially crafted to fit into standard 86-type electrical panel boxes. It sits neatly flat against the wall, hiding messy fiber wires and saving valuable desk space in enterprise campuses, smart homes, and modern offices.
Next-Gen 2.5GbE Ultra-Speed Port: Features a dedicated 2.5 Gigabit Ethernet port alongside a 1GE port, eliminating internet bottlenecks. It is perfect for connecting high-speed Wi-Fi 6/7 routers, network switches, or high-end PCs to unleash speeds beyond 1000 Mbps.
XPON Dual Mode (GPON/EPON): Smart auto-detection automatically adapts to both GPON (ITU-T G.984) and EPON (IEEE 802.3ah) OLT networks, offering maximum deployment flexibility for local ISPs.
Long-Distance Fiber Transmission: Supports a long fiber-optic run of up to 20KM, ensuring stable, low-latency, and lightning-fast connectivity even if the user is far from the distribution point.
Flexible Operation Modes: Fully supports both Router Mode (PPPoE, DHCP, Static IP, NAT) and Bridge Mode for customizable home or office network infrastructures.
Advanced Fiber Protection: Built-in Rogue ONU detection and Hardware Dying Gasp protection prevent network interference and immediately alert the ISP in case of sudden power cut-offs.
Multicast & IPTV Ready: Supports IGMP v1/v2 Snooping to deliver smooth, lag-free multicast streaming for digital IPTV services.
Robust Firewall & Security: Equipped with DDoS protection, URL filtering, Access Control List (ACL), and MAC filtering to keep the fiber network safe from malicious cyber threats.
Dual-Stack Support: Built-in native compatibility with both IPv4 and IPv6 internet protocols.
Carrier-Grade Remote Management: Fully supports TR-069, OMCI, OAM, Web UI, and Telnet, allowing internet providers to handle remote configuration, debugging, and automated firmware updates effortlessly.
The V-SOL V2802PH is a premium, compact, and highly innovative Wall Mount XPON ONU designed to deliver clean, clutter-free, and ultra-high-speed FTTH (Fiber to the Home) deployments across Bangladesh.
Built with an industry-standard 86-type panel form factor, this unique ONU installs directly into wall electrical boxes, seamlessly blending into enterprise campuses, modern apartments, and premium office spaces without taking up any desk space or
leaving messy fiber patch cords exposed.
Powered by a high-performance Realtek XPON chipset, the V2802PH features smart dual-mode auto-access to work flawlessly across both GPON and EPON network systems. Setting it apart from standard ONUs is its dual-LAN configuration—combining a traditional
1GE port with a powerhouse 2.5GE Multi-Gigabit port. This future-proof 2.5GbE port is the perfect gateway to link high-bandwidth external Wi-Fi 6/7 routers, NAS storage systems, or gaming rigs. Backed by carrier-grade remote management tools (OMCI/TR-069) and
advanced optical overload protection up to 20KM, the VSOL V2802PH is the ultimate low-profile solution for ISPs and users who demand elite fiber speeds without the aesthetic mess.
Brand: ONU / VSOL
Title: V-SOL V2802PH Wall Mount XPON ONU (1GE + 2.5GE Ports)
Model: V2802PH
Code: 2110930421
Category: Networking / ISP / ONU
Product Type: ONU
Price: 4000
Warranty: 1
Availability: Available/In Stock
Description:
V-SOL V2802PH Wall Mount XPON ONU (1GE + 2.5GE Ports)
Technical Specifications:
Model: V2802PH
Form Factor: 86-Type Wall Panel Mount Design
Chipset: High-performance Realtek XPON Chipset
PON Interface: 1 × XPON Port (GPON Class B+ / EPON PX20+ Auto Adaptive)
LAN Interfaces: * 1 × 10/100/1000 Mbps Gigabit Ethernet (1GE) Port
1 × 10/100/1000/2500 Mbps Multi-Gigabit Ethernet (2.5GE) Port
Optical Parameters: TX Wavelength: 1310nm, RX Wavelength: 1490nm | TX Optical Power: 0~+4dBm | RX Sensitivity: -27dBm
Transmission Distance: Up to 20 KM
Optical Safety / Overload Protection: -3dBm (EPON) | -8dBm (GPON)
VLAN Support: VLAN Tag Mode, Transparent Mode, Trunk Mode (Max 8 VLANs), 1:1 Translation Mode, Auto VLAN Detection
LED Status Indicators: PWR, PON, LOS, WAN, LAN1 (1GE), LAN2 (2.5GE)
Physical Specs: Net Weight: 160g | Dimensions: 86 × 86 × 33.3 mm (Fits standard 86-type electrical boxes)
Warranty: 1-Year Official Manufacturer Warranty
Key Features:
86-Type Flush Wall Mount Design: Specially crafted to fit into standard 86-type electrical panel boxes. It sits neatly flat against the wall, hiding messy fiber wires and saving valuable desk space in enterprise campuses, smart homes, and modern offices.
Next-Gen 2.5GbE Ultra-Speed Port: Features a dedicated 2.5 Gigabit Ethernet port alongside a 1GE port, eliminating internet bottlenecks. It is perfect for connecting high-speed Wi-Fi 6/7 routers, network switches, or high-end PCs to unleash speeds beyond 1000 Mbps.
XPON Dual Mode (GPON/EPON): Smart auto-detection automatically adapts to both GPON (ITU-T G.984) and EPON (IEEE 802.3ah) OLT networks, offering maximum deployment flexibility for local ISPs.
Long-Distance Fiber Transmission: Supports a long fiber-optic run of up to 20KM, ensuring stable, low-latency, and lightning-fast connectivity even if the user is far from the distribution point.
Flexible Operation Modes: Fully supports both Router Mode (PPPoE, DHCP, Static IP, NAT) and Bridge Mode for customizable home or office network infrastructures.
Advanced Fiber Protection: Built-in Rogue ONU detection and Hardware Dying Gasp protection prevent network interference and immediately alert the ISP in case of sudden power cut-offs.
Multicast & IPTV Ready: Supports IGMP v1/v2 Snooping to deliver smooth, lag-free multicast streaming for digital IPTV services.
Robust Firewall & Security: Equipped with DDoS protection, URL filtering, Access Control List (ACL), and MAC filtering to keep the fiber network safe from malicious cyber threats.
Dual-Stack Support: Built-in native compatibility with both IPv4 and IPv6 internet protocols.
Carrier-Grade Remote Management: Fully supports TR-069, OMCI, OAM, Web UI, and Telnet, allowing internet providers to handle remote configuration, debugging, and automated firmware updates effortlessly.
The V-SOL V2802PH is a premium, compact, and highly innovative Wall Mount XPON ONU designed to deliver clean, clutter-free, and ultra-high-speed FTTH (Fiber to the Home) deployments across Bangladesh.
Built with an industry-standard 86-type panel form factor, this unique ONU installs directly into wall electrical boxes, seamlessly blending into enterprise campuses, modern apartments, and premium office spaces without taking up any desk space or
leaving messy fiber patch cords exposed.
Powered by a high-performance Realtek XPON chipset, the V2802PH features smart dual-mode auto-access to work flawlessly across both GPON and EPON network systems. Setting it apart from standard ONUs is its dual-LAN configuration—combining a traditional
1GE port with a powerhouse 2.5GE Multi-Gigabit port. This future-proof 2.5GbE port is the perfect gateway to link high-bandwidth external Wi-Fi 6/7 routers, NAS storage systems, or gaming rigs. Backed by carrier-grade remote management tools (OMCI/TR-069) and
advanced optical overload protection up to 20KM, the VSOL V2802PH is the ultimate low-profile solution for ISPs and users who demand elite fiber speeds without the aesthetic mess.
