V-SOL V2801D-1GT1 1GE + CATV XPON ONU
Model: V2801D-1GT1
Brand: VSOL
Code: 2110930418
V-SOL V2801D-1GT1 1GE + CATV XPON ONU
Technical Specifications:
Model: V2801D-1GT1
Chipset: High-performance Realtek XPON Chipset
PON Interface: 1 × XPON Port (GPON/EPON Auto Adaptive)
LAN Interface: 1 × 10/100/1000 Mbps Gigabit Ethernet Port
CATV Interface: 1 × RF Output (F-Type Connector)
RF Optical Power: Receive Range: +2 to -15 dBm | AGC Control Range: 0 to -12 dBm
RF Frequency Range: 47–1000 MHz (With RF output level ≥ 70 dBuv)
VLAN Support: 802.1Q, 802.1p, Tag/Untag, QinQ (VLAN Stacking)
LED Status Indicators: Power, PON, LOS, LAN, CATV (RF Status)
Physical Specs: Compact White Body | Weight: ~110g | Dimensions: 118 × 93.5 × 31 mm
Power Input: DC 12V / 0.5A
Warranty: 1-Year Official Manufacturer Warranty
Key Features:
XPON Dual Mode (GPON/EPON): Smart auto-detection seamlessly adapts to both GPON (ITU-T G.984) and EPON (IEEE 802.3ah) OLT networks, offering absolute flexibility for ISPs.
Integrated CATV Receiver: Features a dedicated RF video output port with built-in AGC (Automatic Gain Control) technology to deliver crystal-clear TV broadcasting alongside high-speed internet.
Full Gigabit Wired Speed: Includes 1× 10/100/1000 Mbps auto-adaptive RJ45 Ethernet port for maximum throughput to PCs, high-end routers, or switches.
Flexible Operation Modes: Supports both high-performance Router Mode (PPPoE, DHCP, Static IP) and Bridge Mode for seamless network integration.
IPTV & Multimedia Ready: Features IGMP Snooping (v1/v2/v3) and IGMP Proxy to ensure smooth, lag-free multicast streaming for IPTV services.
Advanced Network & Security: Built with MAC filtering, Access Control (ACL), a robust firewall, and DDoS protection to secure your network perimeter.
Dual-Stack Support: Native compatibility with both IPv4 and IPv6 networking protocols for future-proof connectivity.
Carrier-Grade Remote Management: Fully supports TR-069, OMCI, OAM, Web UI, and Telnet, allowing network admins to easily configure, troubleshoot, and update firmware remotely.
Product Overview:
The V-SOL V2801D (1GT1) is a high-performance, ultra-compact, and budget-friendly XPON ONT/ONU designed specifically for triple-play FTTH (Fiber to the Home) deployments across Bangladesh. Powered by a reliable Realtek chipset,
this dual-mode device automatically detects and switches between GPON and EPON networks, giving local Internet Service Providers (ISPs) maximum operational flexibility and simplified inventory management.
What sets the V2801D apart is its integrated CATV (RF) optical receiver port. This allows ISPs to deliver high-speed broadband internet and premium television services over a single fiber strand. Equipped with a Full Gigabit (1GE) LAN port,
it ensures zero bottlenecking when connected to an external Wi-Fi router or PC. Its compact footprint, low power consumption, and advanced remote management (TR-069/OMCI) make it the ultimate choice for modern, cost-effective residential and commercial fiber networks.
Brand: ONU / VSOL
Title: V-SOL V2801D-1GT1 1GE + CATV XPON ONU
Model: V2801D-1GT1
Code: 2110930418
Category: Networking / ISP / ONU
Product Type: ONU
Price: 2600
Warranty: 1
Availability: Available/In Stock
Description:
V-SOL V2801D-1GT1 1GE + CATV XPON ONU
Technical Specifications:
Model: V2801D-1GT1
Chipset: High-performance Realtek XPON Chipset
PON Interface: 1 × XPON Port (GPON/EPON Auto Adaptive)
LAN Interface: 1 × 10/100/1000 Mbps Gigabit Ethernet Port
CATV Interface: 1 × RF Output (F-Type Connector)
RF Optical Power: Receive Range: +2 to -15 dBm | AGC Control Range: 0 to -12 dBm
RF Frequency Range: 47–1000 MHz (With RF output level ≥ 70 dBuv)
VLAN Support: 802.1Q, 802.1p, Tag/Untag, QinQ (VLAN Stacking)
LED Status Indicators: Power, PON, LOS, LAN, CATV (RF Status)
Physical Specs: Compact White Body | Weight: ~110g | Dimensions: 118 × 93.5 × 31 mm
Power Input: DC 12V / 0.5A
Warranty: 1-Year Official Manufacturer Warranty
Key Features:
XPON Dual Mode (GPON/EPON): Smart auto-detection seamlessly adapts to both GPON (ITU-T G.984) and EPON (IEEE 802.3ah) OLT networks, offering absolute flexibility for ISPs.
Integrated CATV Receiver: Features a dedicated RF video output port with built-in AGC (Automatic Gain Control) technology to deliver crystal-clear TV broadcasting alongside high-speed internet.
Full Gigabit Wired Speed: Includes 1× 10/100/1000 Mbps auto-adaptive RJ45 Ethernet port for maximum throughput to PCs, high-end routers, or switches.
Flexible Operation Modes: Supports both high-performance Router Mode (PPPoE, DHCP, Static IP) and Bridge Mode for seamless network integration.
IPTV & Multimedia Ready: Features IGMP Snooping (v1/v2/v3) and IGMP Proxy to ensure smooth, lag-free multicast streaming for IPTV services.
Advanced Network & Security: Built with MAC filtering, Access Control (ACL), a robust firewall, and DDoS protection to secure your network perimeter.
Dual-Stack Support: Native compatibility with both IPv4 and IPv6 networking protocols for future-proof connectivity.
Carrier-Grade Remote Management: Fully supports TR-069, OMCI, OAM, Web UI, and Telnet, allowing network admins to easily configure, troubleshoot, and update firmware remotely.
Product Overview:
The V-SOL V2801D (1GT1) is a high-performance, ultra-compact, and budget-friendly XPON ONT/ONU designed specifically for triple-play FTTH (Fiber to the Home) deployments across Bangladesh. Powered by a reliable Realtek chipset,
this dual-mode device automatically detects and switches between GPON and EPON networks, giving local Internet Service Providers (ISPs) maximum operational flexibility and simplified inventory management.
What sets the V2801D apart is its integrated CATV (RF) optical receiver port. This allows ISPs to deliver high-speed broadband internet and premium television services over a single fiber strand. Equipped with a Full Gigabit (1GE) LAN port,
it ensures zero bottlenecking when connected to an external Wi-Fi router or PC. Its compact footprint, low power consumption, and advanced remote management (TR-069/OMCI) make it the ultimate choice for modern, cost-effective residential and commercial fiber networks.
