MAXSUN CHALLENGER B450M MICRO ATX MOTHERBOARD

Brand: Motherboard / Maxsun

Title: MAXSUN CHALLENGER B450M MICRO ATX MOTHERBOARD

Model: MS-CHALLENGER-B450M

Code: 122242201

Category: Component / Motherboard AMD / Maxsun

Product Type: Motherboard

Price: 7000

Warranty: 3

Availability: Out of Stock

Description:

Processor

CPU Socket

AMD Socket AM4, support for: AMD Ryzen 5000 G-Series Processors/
AMD Ryzen 5000 Series Processors/
AMD Ryzen 4000 G-Series Processors/
AMD Ryzen 3000 Series Processors

Mainboard

Chipset

AMD B450 Chipset

Memory

Memory

2x DDR4, Maximum Memory Capacity 64GB
Memory Support DDR4 3200(OC)/
2933(OC)/ 2666(OC)/ 2400(OC) MHz
Supports AMD A-XMP OC
Supports Dual-Controller Dual-Channel mode

Storage

Storage

M.2 slot (Key M), type 2242/2280 (supports PCIe 4.0 x4 mode)
4x SATA 6Gb/s ports

Networking & Connectivity

LAN

Realtek RTL8111H 1G LAN

Audio & Microphone

Audio

Realtek ALC897 Codec
5.1-Channel High Definition Audio

Ports

Internal I/O Ports

1x 24-pin Power Connector(ATX_PWR)
1x 4-pin Power Connector(CPU_PWR)
1x CPU Fan
1x System Fan
1x PS/2 interface
1x M.2 slots (Key-M)
4x SATA 6Gb/s ports
1x 4-Pin SPEAKER
1x Front Audio
1x COM_A Port
1x 9-Pin DEBUG_CON
1x CLR CMOS

USB

*Front USB (Total 4 ports)
2x USB 3.2 Gen1 Type A
2x USB 2.0
*Rear USB (Total 4 ports) 2x USB 3.2 Gen1 Type A
2x USB 2.0

Combo

Graphics Card

1x VGA
*Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz
1x HDMI port
*HDMI port supports up to 4K 30Hz
*Graphics specifications may vary between CPU types.

Others

Other Features

RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

Physical Specification

Expansion Slots

1x PCIe 3.0 x16 slot
1x PCIe 3.0 x1 slot

Form Factor

M-ATX

Dimension

220mm x 175mm

Technical Info

LED Indicators

Without Debug LED

Supported OS

Support for Windows 11 64-bit, Windows 10 64-bit

Warranty Information

Warranty

3 Years
