V-SOL V3554-P 48-Port Gigabit PoE Managed Switch

Brand: Switch / VSOL

Title: V-SOL V3554-P 48-Port Gigabit PoE Managed Switch

Model: V3554-P

Code: 216446917

Category: Networking / Switch (PoE) / VSOL

Product Type: Switch

Price: 85000

Warranty: 1

Availability: Available/In Stock

Description:

V-SOL V3554-P 48-Port Gigabit PoE Managed Switch

Technical Specifications:

Model: V3554-P

Switching Capacity: 176 Gbps
Packet Forwarding Rate: 132 Mpps
Fixed Ports: 48 × 10/100/1000 Mbps Base-T RJ45 PoE Ports & 6 × 10G SFP+ Uplink Slots
PoE Standards: IEEE 802.3af (PoE) / IEEE 802.3at (PoE+)
PoE Power Budget: Total 400W (Supports smart power allocation per port)
MAC Address Table: 16K MAC address entries
VLAN Support: 4K VLANs, Voice VLAN, 802.1Q, QinQ, GVRP
Layer 3 Features: Static Routing, RIP, OSPF, IPv4/IPv6 Dual-Stack
Cooling System: Smart fan design with efficient airflow cooling

Physical Specs: Standard 1U 19-inch Rackmount | Dimensions: 440 × 320 × 44 mm

Warranty: 1-Year Official Manufacturer Warranty

Key Features:

Ultra-High 48-Port PoE Density: Equipped with 48 full Gigabit RJ45 ports that support IEEE 802.3af/at PoE/PoE+ standards, making it perfect for powering IP cameras, VoIP phones, and wireless Access Points.

Blazing-Fast 10G Uplinks: Features 6 dedicated 10G SFP+ slots to ensure high-bandwidth connectivity to core networks, preventing bottlenecking and optimizing data aggregation.

Enterprise-Grade Layer 3 Routing: Supports advanced L3 routing capabilities including Static Routing, RIP, and OSPF for efficient traffic management and scalable network segmentation.

Robust Switching Architecture: Delivers a massive 176 Gbps switching capacity and a packet forwarding rate of 132 Mpps, ensuring non-blocking wire-speed data transmissions.

Comprehensive Security & ACL: Enhanced with IP-MAC-Port Binding, Access Control Lists (ACL), 802.1X authentication, Radius/Tacacs+, and DoS attack prevention to safeguard critical enterprise data.

Advanced QoS (Quality of Service): Prioritizes voice, video, and mission-critical traffic using 802.1p CoS and DSCP, ensuring lag-free multimedia and IPTV streaming.

High Reliability & Resiliency: Supports STP, RSTP, MSTP, ERPS (Ethernet Ring Protection Switching), and Link Aggregation (LACP) to maximize network uptime and redundancy.

Carrier-Grade Management: Fully manageable via Web UI, CLI (Command Line Interface), Telnet, SSH, and SNMP (v1/v2c/v3) for easy remote monitoring, configuration, and troubleshooting.

The V-SOL V3554-P is an enterprise-grade, high-density Layer 3 Managed PoE Switch engineered specifically for large-scale enterprise networks, campus setups, and modern surveillance operations. Featuring 48 full Gigabit PoE ports alongside 6 high-speed 10G SFP+ uplinks,
this switch offers the ultimate backbone for businesses looking to centralize power delivery while handling immense data traffic simultaneously.

With its substantial 400W PoE power budget and smart energy allocation, the V3554-P effortlessly powers high-capacity IP devices without requiring extra power adapters. Built for scalability, security, and maximum network uptime,
it integrates advanced L3 routing protocols and multi-layer defense mechanisms. This makes it an exceptionally reliable, high-performance cornerstone for internet service providers (ISPs), corporate environments, and institutional networks across Bangladesh.
