V-SOL V3528-P 24-Port Gigabit PoE+ Managed Switch with 4 SFP Uplinks

Brand: Switch / VSOL

Title: V-SOL V3528-P 24-Port Gigabit PoE+ Managed Switch with 4 SFP Uplinks

Model: V3528-P

Code: 216446916

Category: Networking / Switch (PoE) / VSOL

Product Type: Switch

Price: 49500

Warranty: 1

Availability: Available/In Stock

Description:

V-SOL V3528-P 24-Port Gigabit PoE+ Managed Switch with 4 SFP Uplinks

Technical Specifications:

Model: V3528-P

Switching Capacity: 56 Gbps
Forwarding Rate: 41.66 Mpps
Fixed Ports: 24 × 10/100/1000 Base-T (PoE+) Ports, 4 × 1000 Base-X SFP Uplink Ports
PoE Standards: IEEE 802.3af (PoE) / IEEE 802.3at (PoE+)
PoE Power Budget: Total 370W (Up to 30W per port)
MAC Address Table: 8K
VLAN Support: 4K VLANs, Port-based VLAN, 802.1Q Tag VLAN, Voice VLAN
Lightning Protection: 6KV (Common Mode) / 4KV (Differential Mode)
Cooling System: Smart Fan Design
Power Supply: Built-in AC 100–240V, 50/60Hz

Physical Specs: Standard 19-inch Rack-mountable Iron Case | Dimensions: 440 × 220 × 44 mm

Warranty: 1-Year Official Manufacturer Warranty

Key Features:

Full Gigabit Performance: Equipped with 24× Gigabit RJ45 ports and 4× dedicated SFP slots, delivering massive bandwidth and high-speed data transmission without bottlenecks.

High PoE+ Power Budget: Supports up to 30W per port with a massive total budget of 370W. Perfect for powering high-load devices like IP cameras, VoIP phones, and enterprise Access Points (APs).

Flexible SFP Uplinks: The 4 dedicated Gigabit SFP ports allow long-distance fiber connectivity, making it easy to link with core networks or remote server rooms.

Layer 2 Management Features: Packed with advanced L2 features including IEEE 802.1Q VLAN, Link Aggregation (LACP), IGMP Snooping, QoS, and Loop Protection for optimized network traffic.

Enhanced Security Protocol: Features Access Control Lists (ACL), Port Security, Broadcast Storm Control, and DoS defense to keep your business network safe from malicious attacks.

Intelligent PoE Management: Supports PoE scheduling, power priority settings, and real-time PoE status monitoring via the management dashboard.

Robust Hardware Protection: Built with enterprise-grade 6KV lightning protection to safeguard the switch and connected devices against unexpected power surges.

Easy Management & Maintenance: Supports multiple convenient management modes, including Web UI, CLI (Command Line Interface), Telnet, SSHv2, and SNMP (v1/v2c/v3).

Product Overview:

The V-SOL V3528-P is an enterprise-grade, high-performance Layer 2 Managed PoE+ Switch engineered for scalable corporate networks, smart surveillance setups, and modern SME IT infrastructures. Featuring 24 Gigabit Ethernet ports and 4 dedicated Gigabit SFP fiber
uplinks, this switch ensures seamless data aggregation and ultimate network flexibility.

With a robust 370W total PoE power budget and support for IEEE 802.3at/af standards, the V3528-P simplifies complex deployments by delivering both high-speed data and stable electrical power over a single Ethernet cable. This eliminates the need for extra power
outlets near IP cameras or wireless access points. Housed in a standard 19-inch rack-mountable chassis with 6KV lightning protection and smart cooling, it guarantees 24/7 continuous operation. For network administrators, the switch offers full control through an
intuitive Web UI and advanced L2 management tools, making it a reliable backbone for any expanding network in Bangladesh.
