Jovision JVS-XD2832-HE20K 32CH 5-in-1 32-Channel CloudSEE XVR
Model: JVS-XD2832-HE20K
Brand: Jovision
Code: 161614106
| Display | |
|---|---|
| Interface | 1x HDMI, 1x VGA |
| Resolution | 1280x1024, 1024x768, 1280x800, 1440x900, 1920x1080 |
| OSD | Device ID, Time, Record Setting, Alarm setup, Audio,Camera title |
| Video & Audio | |
| Analog Camera Input | 32Channel, BNC |
| IP Camera Input | Up to 1080p |
| HDCVI Camera | 1080p@25/30fps, 720p@25/30fps |
| AHD Camera | 4MP, 1080p@25/30, 720p@25/30fps |
| Compression | H.264+/H.264 |
| TVI Camera | 1080p@25/30, 720p@25/30fps |
| CVBS Camera | PAL/NTSC |
| Audio In & Out | 8/1, RCA |
| Two-way Talk | 1CH RCA |
| Video Playback | 16ch 2.0MP ;8ch 4.0MP |
| Video port configuration | Full HD: 32CH, Hybrid: 16CH+16CH, Full Network: 32CH |
| Record Rate | Main stream: 4M-N(1~8fps), 1080N(1~18fps), 720P/960H/D1(1~18fps） Sub stream: D1/CIF(1~8/12fps) |
| Search Mode | Time /Date, Alarm, MD, IVP, Auto, Scheduled |
| Record Mode | Manual, Schedule (General, Continuous), MD (Motion Detection, Video Loss, IVP), Alarm Device |
| Audio Compression | G.711U |
| Playback Function | Day view, Hour view, Back Step, Rewind, Pause, Play,Fast Forward, Slow, Step, Snap, Sound on/off, Zoom,Backup to U-Disk |
| Storage | |
| Interface type | 2 SATA Interface |
| Capacity | Up to 6 TB |
| Backup Mode | USB |
| Network | |
| Interface | 1 RJ-45 Port (100M) |
| Network Function | TCP/IP, DHCP, DNS, DDNS, HTTPS, HTTP, |
| Interoperability | ONVIF 2.4 |
| Smart Phone | iPhone, Android |
| General | |
| Consumption | ≤ 20W |
| Operation Temperature | 00C~ 550C |
| Working Humidity | 10% to 90% |
| Power Source | DC12V |
| Dimension | 405x338x135mm (15.9×13.3×5.3 inch) |
| Weight | ≤ 3kg (6.6 lb.) |
Brand: Jovision
Title: Jovision JVS-XD2832-HE20K 32CH 5-in-1 32-Channel CloudSEE XVR
Model: JVS-XD2832-HE20K
Code: 161614106
Category: Security / CCTV DVR / Jovision
Product Type: DVR
Price: 23500
Warranty: 1
Availability: Available/In Stock
Description:
Display
Interface
1x HDMI, 1x VGA
Resolution
1280x1024, 1024x768, 1280x800, 1440x900, 1920x1080
OSD
Device ID, Time, Record Setting, Alarm setup, Audio,Camera title
Video & Audio
Analog Camera Input
32Channel, BNC
IP Camera Input
Up to 1080p
HDCVI Camera
1080p@25/30fps, 720p@25/30fps
AHD Camera
4MP, 1080p@25/30, 720p@25/30fps
Compression
H.264+/H.264
TVI Camera
1080p@25/30, 720p@25/30fps
CVBS Camera
PAL/NTSC
Audio In & Out
8/1, RCA
Two-way Talk
1CH RCA
Video Playback
16ch 2.0MP ;8ch 4.0MP
Video port configuration
Full HD: 32CH, Hybrid: 16CH+16CH, Full Network: 32CH
Record Rate
Main stream: 4M-N(1~8fps), 1080N(1~18fps), 720P/960H/D1(1~18fps） Sub stream: D1/CIF(1~8/12fps)
Search Mode
Time /Date, Alarm, MD, IVP, Auto, Scheduled
Record Mode
Manual, Schedule (General, Continuous), MD (Motion Detection, Video Loss, IVP), Alarm Device
Audio Compression
G.711U
Playback Function
Day view, Hour view, Back Step, Rewind, Pause, Play,Fast Forward, Slow, Step, Snap, Sound on/off, Zoom,Backup to U-Disk
Storage
Interface type
2 SATA Interface
Capacity
Up to 6 TB
Backup Mode
USB
Network
Interface
1 RJ-45 Port (100M)
Network Function
TCP/IP, DHCP, DNS, DDNS, HTTPS, HTTP,
Interoperability
ONVIF 2.4
Smart Phone
iPhone, Android
General
Consumption
≤ 20W
Operation Temperature
00C~ 550C
Working Humidity
10% to 90%
Power Source
DC12V
Dimension
405x338x135mm (15.9×13.3×5.3 inch)
Weight
≤ 3kg (6.6 lb.)
