DJI Inspire 3 Drone

Brand: DJI

Title: DJI Inspire 3 Drone

Model: INSPIRE-3

Code: 1812133907

Category: Gadget / Drone / DJI

Product Type: Drone

Price: 200000

Warranty: 1

Availability: Out of Stock

Description:

Aircraft

Weight (Battery & Propellers Included)

Approx. 3,995 g (includes gimbal camera, two batteries, lens, PROSSD, and propellers)

Diagonal Size (Propellers Excluded)

Landing Gear Raised: 695 mm
Landing Gear Lowered: 685 mm

Max Ascent Speed

8 m/s

Max Descent Speed

Vertical: 8 m/s
Tilt: 10 m/s

Max Speed

94 kph

Max Service Ceiling Above Sea Level

Standard Propellers: 3800 m
High-Altitude Propellers: 7000 m

Max Wind Speed Resistance

Takeoff/land: 12 m/s
In-flight: 14 m/s

Max Flight Time

Approx. 28 minutes (landing gear lowered)
Approx. 26 minutes (landing gear raised)

Operating Temperature Range

-20° to 40° C (-4° to 104° F)

Satellite Positioning Systems

GPS + Galileo + BeiDou

Hover Accuracy Range

Vertical:
±0.1 m (with vision positioning)
±0.5 m (with GNSS positioning)
±0.1 m (with RTK positioning)
Horizontal:
±0.3 m (with vision positioning)
±0.5 m (with GNSS positioning)
±0.1 m (with RTK positioning)

Others

RTK Positioning Accuracy (RTK fix):
1 cm + 1 PPM (horizontal)
1.5 cm + 1 PPM (vertical)

Gimbal

Controllable Range

Tilt (landing gear lowered):
Before gimbal tilt limit extension: -90° to +30°
After gimbal tilt limit extension: -115° to +100°
Tilt (landing gear raised):
Before gimbal tilt limit extension: -90° to +30°
After gimbal tilt limit extension: -140° to +75°
Roll: ±20°
Pan: ±300°

Max Controllable Angular Speed

With DJI RC Plus:
Tilt: 120°/s
Roll: 180°/s
Pan: 270°/s
With DJI Master Wheels:
Tilt: 432°/s
Roll: 432°/s
Pan: 432°/s

Angular Vibration Range

Hovering: ±0.002°
Flying: ±0.004°

Others

Sensor: 35mm full-frame CMOS
Max Resolution:
Photo: 8192×5456
Video: 8192×4320

Vision System

Vision System

Downward / Upward / Forward / Backward / Left / Right

Velocity Range

Forward
Measurement Range: 4.9 to 157.5' / 1.5 to 48 m
Max Speed: 33.6 mph / 15 m/s
Field of View: 103° (Vertical) / 90° (Horizontal)
Backward
Measurement Range: 4.9 to 157.5' / 1.5 to 48 m
Max Speed: 33.6 mph / 15 m/s
Field of View: 90° (Horizontal) / 103° (Vertical)
Lateral
Measurement Range: 4.9 to 137.8' / 1.5 to 42 m
Max Speed: 33.6 mph / 15 m/s
Field of View: 90° (Horizontal) / 85° (Vertical)
Upward
Measurement Range: 0.7 to 42.7' / 0.2 to 13 m
Max Speed: 13.4 mph / 6 m/s
Field of View: 100° (Vertical) / 90° (Horizontal)
Downward
Measurement Range: 1.0 to 59.1' / 0.3 to 18 m
Max Speed: 13.4 mph / 6 m/s
Field of View: 130° (Vertical) / 160° (Horizontal)

Operating Environment

Surface with Clear Patterns at >15 lux

Infrared Sensing System

FOV

161°

Camera

Sensor

35mm full-frame CMOS

Lens

Supported Lenses:
DL 18 mm F2.8 ASPH Lens
DL 24 mm F2.8 LS ASPH Lens
DL 35 mm F2.8 LS ASPH Lens
DL 50 mm F2.8 LS ASPH Lens

ISO Range

ISO: 100-25600
Video
EI: 200-6400

Electronic Shutter Speed

8-1/8000 s

Image Size

DNG / JPEG
(8192 x 5456)

Still Photography Modes

DNG / JPEG
(8192 x 5456)

Video Recording Modes

CinemaDNG
8192 x 4320 at 23.98/24.00/25 fps [849 to 885 MB/s]
7680 x 4320 at 23.98/24.00/25 fps [796 to 829 MB/s]
4096 x 2160 at 23.98/24.00/25/29.97/30.00/48.00/50/59.94/60.00/72/75/96/100 fps [212 to 885 MB/s]
3840 x 2160 at 23.98/24.00/25/29.97/30.00/48.00/50/59.94/60.00/72/75/96/100 fps [199 to 829 MB/s]
5568 x 2952 at 23.98/24.00/25/29.97/30.00/48.00/50 fps [394 to 822 MB/s]
5248 x 2952 at 23.98/24.00/25/29.97/30.00/48.00/50 fps [372 to 775 MB/s]
ProRes RAW
8192 x 4320 at 23.98/24.00/25/29.97/30.00/48.00/50/59.94/60.00 fps [425 to 531 MB/s]
7680 x 4320 at 23.98/24.00/25/29.97/30.00/48.00/50/59.94/60.00 fps [398 to 498 MB/s]
8192 x 3424 at 72/75 fps [505 to 526 MB/s]
4096 x 2160 at 23.98/24.00/25/29.97/30.00/48.00/50/59.94/60.00/72/75/96/100/120 fps [106 to 265 MB/s]
3840 x 2160 at 23.98/24.00/25/29.97/30.00/48.00/50/59.94/60.00/72/75/96/100/120 fps [100 to 249 MB/s]
5568 x 2952 at 23.98/24.00/25/29.97/30.00/48.00/50/59.94/60.00 fps [198 to 494 MB/s]
5248 x 2952 at 23.98/24.00/25/29.97/30.00/48.00/50/59.94/60.00 fps [186 to 465 MB/s]
MOV/ProRes 422 HQ
8192 x 4320 at 23.98/24.00/25/29.97/30.00 fps [377 to 471 MB/s]
7680 x 4320 at 23.98/24.00/25/29.97/30.00 fps [352 to 442 MB/s]
4096 x 2160 at 23.98/24.00/25/29.97/30.00/48.00/50/59.94/60.00/72/75/96/100/120 fps [94 to 471 MB/s]
3840 x 2160 at 23.98/24.00/25/29.97/30.00/48.00/50/59.94/60.00/72/75/96/100/120 fps [88 to 442 MB/s]
H.264/MOV
4096 x 2160 at 23.98/24.00/25/29.97/30.00/48.00/50/59.94/60.00/72/75/96/100/120 fps [19 to 38 MB/s]
3840 x 2160 at 23.98/24.00/25/29.97/30.00/48.00/50/59.94/60.00/72/75/96/100/120 fps [19 to 38 MB/s]


JPG, DNG

Video

MOV, CinemaDNG

Supported SD Cards

DJI PROSSD 1TB

Operating Temperature Range

-20° to 50 °C (-4° to 122° F)

Remote Controller

Operating Frequency

2.4000-2.4835 GHz
5.725 GHz-5.850 GHz

Max Transmission Distance

Single Control Mode:
FPV Camera: approx. 15 km (FCC), 8 km (CE/SRRC/MIC)
Gimbal Camera (1080p/60fps live feeds): approx. 13 km (FCC), 7 km (CE/SRRC/MIC)
Gimbal Camera (4K/30fps live feeds): approx. 5 km (FCC), 3 km (CE/SRRC/MIC)
Dual-Control Mode:
FPV Camera: approx. 12 km (FCC), 6.4 km (CE/SRRC/MIC)
Gimbal Camera (1080p/60fps live feeds): approx. 11.2 km (FCC), 5.6 km (CE/SRRC/MIC)
Gimbal Camera (4K/30fps live feeds): approx. 4 km (FCC), 2.4 km (CE/SRRC/MIC)

Operating Temperature Range

-20° to 50 °C (-4° to 122° F)

Battery

Built-in Battery: 3250mAh-7.2V (a set)
External Battery: WB37 Intelligent Battery

Transmitter Power (EIRP)

2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.1 GHz: <23 dBm (CE)
5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE)

Operating Current/Voltage

23.1 V

Video Output Port

HDMI

Charger

Voltage

26.4 V, 7.8 A

Rated Power

476 W

Others

AC Input Power: 100 to 240 VAC, 50 / 60 Hz at 8 A


Intelligent Flight Battery

Capacity

4280 mAh

Voltage

23.1 V

Battery Type

Li-ion

Energy

98.8 Wh

Net Weight

Approx. 470 g

Charging Temperature Range

-20° to 40° C (-4° to 104° F)

Max Charging Power

205.5 W

App / Live View

Mobile App

DJI Pilot 2

Live View Quality

FPV Camera: Up to 1080p/60fps
Gimbal Camera: Up to 1080p/60fps, 4K/30fps

Latency

FPV Camera: 90 ms
Gimbal Camera: 90 ms

Warranty

Warranty

1-Year DJI Warranty (Warranty will be void if the product has been physically damaged. Claims must be made directly through DJI support.)
