Dahua DH-XVR4232AN-I 32-Channel XVR

Brand: Security / Dahua

Title: Dahua DH-XVR4232AN-I 32-Channel XVR

Model: DH-XVR4232AN-I

Code: 16161512

Category: Security / CCTV DVR / Dahua

Product Type: XVR

Price: 25000

Warranty: 1

Availability: Available/In Stock

Description:

DVR / NVR / XVR Specification

Display

Interface:- 1 HDMI, 1 VGA, 1 TV
Resolution:- 1920×1080, 1280×1024, 1280×720, 1024×768
Multi-Screen Display:- 1/4/8/9/16/25
OSD:- Camera title, Time, Video loss, Camera lock,
Motion detection, Recording

External Interface

USB:- 2 USB Ports (1 USB 3.0,1 USB 2.0)
RS485:- 1 Port, for PTZ Control

Network

Interface:- 1 RJ-45 Port (1000M)
Ethernet Port:- HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP,
NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm
Server,P2P, IP Search (Support Dahua IP camera, DVR, NVS, etc.)
Maximum User Access:- 128 users
Smart Phone:- iPhone, iPad, Android
Interoperability:- ONVIF 2.42, CGI Conformant

Playback and Backup

Sync Playback:- 1/4/9/16
Search Mode:- Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function:- Play, Pause, Stop, Rewind, Fast play, Slow Play, Next
File, Previous File, Next Camera, Previous Camera,
Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode:- USB Device/Network

Recording

Compression:- H.264
Resolution:- 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF
Record Rate:- Main Stream: 1080N(12fps)/720P(15fps)/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
Sub steram:CIF/QCIF(1~7fps)
Bit Rate:- 1Kbps ~ 4096Kbps Per Channel
Record Mode:- Manual, Schedule (Regular, Continuous), MD
(Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval:- 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec,
Post-record: 10 ~ 300 sec

Storage

Disk Group:- Yes
Internal HDD:- 2 SATA Ports, up to 8TB capacity for each disk

System

Main Processor:- Industrial-grade processor
Operating System:- Embedded Linux
Operating Interface:- Web; Local GUI

Video and Audio

Analog Camera Input:-
32 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect

Camera Input:-
1. CVI: 1080p@25/30 fps; 720p@25/30 fps.
2. TVI: 1080p@25/30 fps; 720p@25/30 fps.
3. AHD: 1080p@25/30 fps; 720p@25/30 fps.

IP Camera Input:-
Up to 20 channels of IPC access
4 IP channels by default + 16 channels (analog channels are converted to IP channels)
incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps
After IP channels are added beyond the existing channels, the AI Function SMD will be disabled.

Encoding Capacity:-
Main stream: the 1st channel 1080N/720p@(1 fps–25/30 fps), others 1080N/720p@(1 fps–15 fps); 960H/D1/CIF@(1 fps–25/30 fps)
Sub stream: CIF@(1 fps–7 fps)

Dual-stream:- Yes
Video Bit Rate:- 32 kbps–4096 kbps
Audio Sampling:- 8 kHz, 16 bit
Audio Bit Rate:- 64 kbps Video Output:-
1 HDMI, 1 VGA，1 TV
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720

Multi-screen Display:- 1/4/8/9/16/25/36
Third-party Camera Access:- Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF

General

Operating Humidity

10%–90% (RH), non-condensing

Storage Temperature

–20 °C to +60 °C (–4 °F to +140 °F)

Power

Power Supply:- 12 VDC, 4 A

Power Consumption

<12 W(without HDD)

Dimensions

Product Dimensions:-
375.0 mm × 289.6 mm × 53.0 mm (14.76" × 11.40" × 2.09" ) (W × D × H)

Packaging Dimensions:-
433.0 mm × 141.0 mm × 366.0 mm (17.05" × 5.55" × 14.41") (W × D × H)

Weight

Net Weight:- 1.92 kg (4.23 lb)
Gross Weight:- 3.09 kg (6.81 lb)

Warranty Information

Warranty

01-Years Warranty
