D-Link CAT 6 UTP Cable 305M 23AWG Blue -Original
Model: PANDUIT-CAT-6-UTP-CABLE
Brand: D Link
Code: 2112541816
- Electrical performance: Certified channel performance in a 4-connector configuration up to
- 100 meters and meets ANSI/TIA-568-C.2 Category 6 and ISO
- 11801 Class E standards at swept frequencies up to 250MHz
- Conductors/insulators: Plenum – 23 AWG solid copper covered by FEP/polyolefin insulation
- Riser – 23 AWG solid copper covered by polyolefin insulation
- Flame rating: Plenum – NFPA 262
- Riser – UL1666
- PoE compliance: Meets IEEE 802.3af and IEEE 802.3at for PoE applications
- Installation tension: 25 lbf (110N) maximum
- Temperature rating: 32°F to 122°F (0°C to 50°C) during installation
- -4°F to 167°F (-20°C to 75°C) during operation (Riser)
- -4°F to 140°F (-20°C to 60°C) during operation (Plenum)
- Cable jacket: Plenum – low smoke, flame-retardant PVC
- Riser – flame-retardant PVC
- Cable diameter: Plenum – 0.224 in. (5.7mm) nominal
- Riser – 0.210 in. (5.3mm) nominal
- Cable weight: Plenum – 29 lbs./1000 ft. (13 kg/305m)
- Riser – 22 lbs./1000 ft. (10 kg/305m)
- Packaging: 1000 ft. (305m) in an easy payout carton
- Package tested to ISTA Procedure1A
Brand: UTP Cable / D Link
Title: D-Link CAT 6 UTP Cable 305M 23AWG Blue -Original
Model: PANDUIT-CAT-6-UTP-CABLE
Code: 2112541816
Category: Networking / Networking Cable / UTP (CAT6)
Product Type: UTP Cable
Price: 16700
Warranty: 0
Availability: Available/In Stock
Description:
Electrical performance: Certified channel performance in a 4-connector configuration up to100 meters and meets ANSI/TIA-568-C.2 Category 6 and ISO11801 Class E standards at swept frequencies up to 250MHzConductors/insulators: Plenum – 23 AWG solid copper covered by FEP/polyolefin insulationRiser – 23 AWG solid copper covered by polyolefin insulationFlame rating: Plenum – NFPA 262Riser – UL1666PoE compliance: Meets IEEE 802.3af and IEEE 802.3at for PoE applicationsInstallation tension: 25 lbf (110N) maximumTemperature rating: 32°F to 122°F (0°C to 50°C) during installation-4°F to 167°F (-20°C to 75°C) during operation (Riser)-4°F to 140°F (-20°C to 60°C) during operation (Plenum)Cable jacket: Plenum – low smoke, flame-retardant PVCRiser – flame-retardant PVCCable diameter: Plenum – 0.224 in. (5.7mm) nominalRiser – 0.210 in. (5.3mm) nominalCable weight: Plenum – 29 lbs./1000 ft. (13 kg/305m)Riser – 22 lbs./1000 ft. (10 kg/305m)Packaging: 1000 ft. (305m) in an easy payout cartonPackage tested to ISTA Procedure1A
