Afox AMD B450-MA AM4 Socket Motherboard

Brand: Afox

Title: Afox AMD B450-MA AM4 Socket Motherboard

Model: AFOX-B450-MA

Code: 12229801

Category: Component

Sub Category: Motherboard AMD

Sub-Sub Category: Afox

Price: 9300

Offer Status: 0

Description:

Platform: AMD Socket AM4
Model Name: B450-MA-V2
Chipset: Supports: AMD Ryzen 5000 Series/Ryzen 5000 G Series/Ryzen 4000 G Series and Ryzen 3000 Series processors
CPU Supports: AMD Ryzen series CPU
FSB: 2133 / 2400 / 2666 / 2800(O.C.) / 3000(O.C.) / 3200(O.C.) MHz
Memory: Dual Channel DDR4 2133 / 2400 / 2666 / 2800(O.C.) / 3000(O.C.) / 3200(O.C.) MHz  1.2V
Dimm: 2 x Memory Slots (Max. capacity of system memory 64GB)
Onboard Graphics: Integrated AMD Radeon™ Vega series / R Series graphics
PCI/PCI-E Slots: 1 x PCI Express x16 3.0 slot, 2 x PCI Express x1 slot
SATA: 4 x SATA3, 1 x M.2 (PCIe NVMe Gen3 x4 & SATA3)
IDE: N/A
Audio: Realtek 662 on board, Supports 6-channel audio-out
LAN: Realtek RTL8111 1000Mbps Ethernet on board
Back Panel I/Os:
1 x HDMI Port
1 x D-Sub (VGA) Port
1 x DVI Port
1 x PS/2 Mouse Port
1 x PS/2 Keyboard Port
4 x USB 3.0 Ports
2 x USB 2.0 Ports
1 x RJ-45 LAN Port
3 x HD Audio Jack (Line in / Front Speaker / Microphone)
ON-Board Pinheaders/Connectors:
1 x USB 2.0 pin-header (supports additional 2 USB 2.0s)
1 x USB 3.0 pin-header (supports additional 2 USB 3.0s)
1 x Front Panel Audio pin-header and 1 x Front Panel COM pin-header
BIOS: UEFI BIOS
Form Factor: Micro-ATX (22 x 23 cm)
Mounting: 6 mounting holes
Accessories:
1 x SATA II cable
1 x I/O Rear Panel
1 x User Manual
1 x Driver CD
