Tenda HG1 Gpon Single Port Gigabit Optical Network Terminal (ONU)
1,275 TK
In Stock: Yes
Model: HG1
Brand: Tenda
Code: 2110930410
Model: HG1
Brand: Tenda
Code: 2110930410
Category:Networking
| PON Standards | ITU G.984.1, ITU G984.2, ITU G984.3, ITU G984.4 |
| Interfaces | 1*SC/APC XPON Port, 1*1000Mbps RJ45 LAN Port, 1*DC Port |
| LED Indicator | LAN，LOS，PON，PWR |
| Button | 1 RESET Button |
| Optical Mode | Class B+ |
| Optical Wavelength | Transmit at 1310nm, Receive at 1490nm |
| Transmission Distance | 20km Max |
| Bandwidth | Upstream 1.25Gbps Max, Downstream 2.5Gbps Max |
| Dimension | 59*57*23mm(W*D*H) |
| TX Power | 0.5~5dBm |
| RX Power | -28~-8dBm |
| External Power Supply | DC 9V /0.6A |
| Power Consumption | ≤5.4w |
| DHCP Server | Server, Client, DHCP Client List, Address Reservation, DHCP Relay |
| WAN Connection | PPPoE , Dynamic IP, Static IP, Bridge |
| Business Type | Internet |
| IP Version | IPv4, IPv6 |
| Services | DHCP, Dynamic DNS |
| Firewall | ALG, IP Filter ,Port Filter, Mac Filter, URL Filter Port Forwarding， DMZ |
| IPv6 | Radvd, DHCPv6, MLD Proxy, MLD Snooping |
| Diagnostics | Ping, Ping6, Tracert, Tracert6 |
| Operation Temperature | 0°c ~ 45°c |
| Storage Temperature | -40°c ~ 70°c |
| Operating Humidity | 10% ~ 90% （Non-condensing） |
| Storage Humidity | 5% ~ 90% (Non-condensing) |
| Package Contents | 1*HG1,1* Power adapter,1* Quick install guide |
| Certification | CE, FCC, RoHS, Anatel |
Brand: Tenda
Title: Tenda HG1 Gpon Single Port Gigabit Optical Network Terminal (ONU)
Model: HG1
Code: 2110930410
Category: Networking / ISP / ONU
Product Type: Onu
Price: 1275
Warranty: 0
Availability: Available/In Stock
Description:
PON Standards
ITU G.984.1, ITU G984.2, ITU G984.3, ITU G984.4Interfaces
1*SC/APC XPON Port, 1*1000Mbps RJ45 LAN Port, 1*DC PortLED Indicator
LAN，LOS，PON，PWRButton
1 RESET ButtonOptical Mode
Class B+Optical Wavelength
Transmit at 1310nm, Receive at 1490nmTransmission Distance
20km MaxBandwidth
Upstream 1.25Gbps Max, Downstream 2.5Gbps MaxDimension
59*57*23mm(W*D*H)TX Power
0.5~5dBmRX Power
-28~-8dBmExternal Power Supply
DC 9V /0.6APower Consumption
≤5.4wDHCP Server
Server, Client, DHCP Client List, Address Reservation, DHCP RelayWAN Connection
PPPoE , Dynamic IP, Static IP, BridgeBusiness Type
InternetIP Version
IPv4, IPv6Services
DHCP, Dynamic DNSFirewall
ALG, IP Filter ,Port Filter, Mac Filter, URL Filter Port Forwarding， DMZIPv6
Radvd, DHCPv6, MLD Proxy, MLD SnoopingDiagnostics
Ping, Ping6, Tracert, Tracert6Operation Temperature
0°c ~ 45°cStorage Temperature
-40°c ~ 70°cOperating Humidity
10% ~ 90% （Non-condensing）Storage Humidity
5% ~ 90% (Non-condensing)Package Contents
1*HG1,1* Power adapter,1* Quick install guideCertification
CE, FCC, RoHS, AnatelNo Reviews
