NZXT H7 Flow RGB 2024 Edition Mid-Tower ATX Airflow Casing - Black

Brand: NZXT

Title: NZXT H7 Flow RGB 2024 Edition Mid-Tower ATX Airflow Casing - Black

Model: H7-FLOW-RGB-2024-EDITION

Code: 127820016

Category: Component

Sub Category: Casing

Sub-Sub Category: NZXT

Price: 18500

Offer Status: 0

Description:

General

Model: H7 Flow RGB 2024 Edition
Model Number: CM-H72FB-R1
Type: Mid-Tower
Color: Black

Key Specs

Motherboard Support: E-ATX (Up to 277mm), ATX, Micro-ATX, Mini-ITX
Enclosure Type: Mid-Tower
Case Material: SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted Tempered Glass (Black)

Compatibility & Clearance

CPU Cooler Height: Up to 185mm
GPU Length: Up to 410 mm
PSU Length: Up to 200 mm
Cable Management: Up to 34.5 mm
Top Mounted 140mm / 280mm Radiator & Fan Combined Thickness: Up to 57 mm

Expansion Slots

Standard: 7
Vertical: 0

Drive Bays

2.5": 2+2
3.5": 2

Fan Support

Front: 3 x 120 mm / 3 x 140 mm (1 x F360 RGB Core included)
Top: 3 x 120 mm / 2 x 140 mm
Bottom: 3 x 120 mm
Rear: 1 x 120 mm / 1 x 140 mm
Filters: High-Performance Mesh

Fan Specs

Model: F360 RGB Core Fan (Case Version)
Speed: 1,700 ± 200 RPM
Airflow: 50.1 CFM
Static: 1.27 mm-H₂O
Noise: 23.3 dBA
Fan Connector: 3-pin

Fans Included

1x F360 RGB Core (pre-installed, case version)

Radiator Support

Front: Up to 420 mm
Top: Up to 360mm
Rear: Up to 140mm

Front I/O Ports

USB 3.2 Gen 1 Type-A: 2
USB 3.2 Gen 2x2 Type-C (20 Gbps): 1
Headset Audio Jack: 1

Inside the Box

H7 Flow RGB: 1
F360 RGB Core (pre-installed, case version): 1
Installation Accessories: 1
Manual: 1

Weight & Dimensions

Height (With Feet): 544 mm
Width: 244 mm
Depth: 468 mm
Weight: 11.13 kg
