NZXT H5 Flow 2024 Compact Mid-tower Airflow Casing

Brand: NZXT

Title: NZXT H5 Flow 2024 Compact Mid-tower Airflow Casing

Model: CC-H52FB-01

Code: 127820002

Category: Component

Sub Category: Casing

Sub-Sub Category: NZXT

Price: 10000

Offer Status: 0

Description:

Case Type

Type

Mid-Tower

Tempered Glass Panel

Yes

Motherboard Support

E-ATX (Up to 277 mm wide), ATX, Micro-ATX, Mini-ITX

External Features

Color(s)

Black

Material

SGCC Steel, Ultra-clear Tempered Glass, Dark Tinted Tempered Glass (Black only)

Weight

7.28 kg / 16.04 lb

Dimensions

Height (with feet): 465 mm / 18.31 in
Width: 225 mm / 8.86 in
Depth: 430 mm / 16.93 in

Front Ports

1 x USB 3.2 Type-A
1 x USB 3.2 Gen 2x2 Type-C (20 Gbps)
1 x Headset Audio Jack

Expansion Slots

Standard: 7

Radiator Support

Front: Up to 360 mm
Top: Up to 240 mm (280mm with low-profile memory only)

Fan Support

Front: 3 x 120 mm / 2 x 140 mm (1 x F120Q Case Version included)
Top: 2 x 120 mm / 2 x 140 mm
Bottom: 2 x 120 mm
Rear: 1 x 120 mm (1 x F120Q Case Version included)

Pre- Installed Fans

Front: 2 x 120 mm
Rear: 1 x 120 mm

Drive Bays

2.5": 2
3.5": 1

Additional Feature

PSU

Not Included

Clearance Space

Maximum CPU Cooler Height

Up to 170 mm

Maximum Graphics Card Length

Up to 410 mm

Maximum PSU Length

Up to 200 mm

Warranty

Warranty

No Warranty
