Maxsun Challenger B760ITX D5 WIFI Intel Motherboard

Brand: Motherboard / Intel

Title: Maxsun Challenger B760ITX D5 WIFI Intel Motherboard

Model: MAXSUN-CHALLENGER-B760ITX-D5-WIFI

Code: 123242002

Category: Component / Motherboard Intel / Maxsun

Product Type: Motherboard

Price: 16000

Warranty: 3

Availability: Available/In Stock

Description:

Brand

Maxsun

Model

Maxsun Challenger B760ITX D5 WIFI

Chipset

Intel B760 High Speed Chipset

CPU Support

12th/13th/14th Gen Intel® Core™ Processors, Pentium® Gold, and Celeron® Processors

Socket

LGA 1700

Memory

2x DDR5, Maximum 96GB, Supports 4800 MHz /XMP/OC, Dual-Channel Mode

XMP Support

Intel® XMP 2.0 OC

Onboard Graphics

2x DP1.4 (up to 4096x2160@60Hz), 1x HDMI 2.0 (up to 4096x2160@60Hz), 1x HDMI 1.4 (up to 4096x2160@30Hz)

Expansion Slot

1x PCIe 5.0 x16

SSD

1x M.2 (Front, Gen4 x4), 1x M.2 (Back, Gen4 x4), 4x SATA 3.0 ports

USB Ports

5x Onboard USB Pins, Rear USB Ports

LAN

2.5Gb+1Gb Dual LAN Ports

Audio

Realtek® ALC897 Codec

Internal I/O

1x 24-pin ATX_PWR, 1x 8-pin CPU_PWR, 1x CPU Fan, 3x System Fan, 1x M.2 (Key-M), 4x SATA 6Gb/s, 1x CLR_CMOS, 1x 4-Pin BUZZER, 1x Front Audio, 1x COM Port

Operating System

Windows® 10 64-bit, Windows® 11 64-bit

Form Factor

ITX (170mm x 170mm)

Warranty

3 Years
