DJI OM 5 3 Axis Stable Gimbal

Brand: Gimbal / DJI

Title: DJI OM 5 3 Axis Stable Gimbal

Model: OM-5

Code: 1811932301

Category: Gadget / Gimbal / DJI

Product Type: Gimbal

Price: 14500

Warranty: 0

Availability: Available/In Stock

Description:

General

Dimension

Gimbal Dimensions:
Unfolded: 264.5×111.1×92.3 mm
Folded: 174.7×74.6×37 mm

Grip Tripod
Gimbal Dimensions
Length: 138 mm
Diameter: 32 mm

Weight

Gimbal: 292 g
Magnetic Phone Clamp: 34 g
Compatible Phone Weight: 230 ± 60 g
Grip Tripod: 72 g


Compatibility

Smartphone Vlogging and YouTube Live Video

Battery

Type

Pouch Cell

Capacity

1000 mAh


Energy

7.74Wh

Voltage

6-8.8 V

Charging Temperature

5° to 40°C (41° to 104°F)

Operating Temperature

0° to 40°C (32° to 104°F)

Operating Time

6.4 hrs (under ideal conditions with the gimbal fully balanced)

Charging Time

1.5 hrs (measured with a 10W charger)

Ports

Gimbal Charging Port: USB-C

Mount

1/4" Threaded Hole

Gimbal

Consumption

1.2 W (under ideal conditions with the gimbal fully balanced)

Mechanical Range

Pan: -161.12° to 172.08°
Roll: -127.05° to 208.95°
Tilt: -101.46° to 229.54°

Width of Compatible

67-84 mm

Thickness of Compatible

6.9-10 mm

Wireless

Bluetooth Low Energy 5.0

Warranty

Warranty

1-Year DJI Warranty (Warranty will be void if the product has been physically damaged. Claims must be made directly through DJI support.)
